Product Summary
The 78L05 is a 3-Terminal Positive Regulator. It employs internal current limiting and thermal shutdown, making them essentially indestructible. If adequate heat-sink is provided, it can deliver up to 100 mA output current. The 78L05 is intended as fixed voltage regulators in a wide range of applications including local or on-card regulation for elimination of noise and distribution problems associated with single point regulation. In addition, the 78L05 can be used with power pass elements to make high- current voltage regulators. The 78L05 used as Zener diode/resistor combination replacement, offers an effective output impedance improvement of typically two orders of magnitude, along with lower quiescent current and lower noise.
Parametrics
78L05 absolute maximum ratings: (1)Input Voltage: 35V; (2)Storage Temperature: 65℃ to +150℃; (3)Operating Junction Temperature: 0℃ to 125℃; (4)ESD Susceptibility: 1kV.
Features
78L05 features: (1)in micro SMD package; (2)Output voltage tolerances of ±5% over the temperature range; (3)Output current of 100 mA; (4)Internal thermal overload protection; (5)Output transistor safe area protection; (6)Internal short circuit current limit; (7)Available in plastic TO-92 and plastic SO-8 low profile packages; (8)No external components.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 78L05 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
78L05AC |
Other |
|
Data Sheet |
Negotiable |
|
||||
