Product Summary
The AT25DF321-SH-T is a serial interface Flash memory device designed for use in a wide variety of high-volume consumer based applications in which program code is shadowed from Flash memory into embedded or external RAM for execution. The flexible erase architecture of the AT25DF321-SH-T, with its erase granularity as small as 4-Kbytes, makes it ideal for data storage as well, eliminating the need for additional data storage EEPROM devices.
Parametrics
AT25DF321-SH-T absolute maximum ratings: (1)Operating Temperature: 55℃ to +125℃ ; (2)Storage Temperature: 65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: 1.0V to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0 mA.
Features
AT25DF321-SH-T features: (1)Low-voltage and Standard-voltage Operation; (2)Internally Organized 65,536 x 8; (3)Two-wire Serial Interface; (4)Schmitt Triggers, Filtered Inputs for Noise Suppression; (5)Bidirectional Data Transfer Protocol; (6)Self-timed Write Cycle (5 ms Max); (7)High Reliability.
Diagrams
 |
