Product Summary

The EFOS4004E5 is an eramic Resonator. It is applicated for Clock generator for microprocessors, Carrier between telecommunication equipment (Telephone to telephone, personal computer to printer).

Parametrics

EFOS4004E5 absolute maximum ratings: (1)Oscillation Built-in Frequency: 4.00 MHz ±0.5 %; (2)Loop Gain: 10 dB; (3)Temperature Maximum frequency drift: ± 0.2 %, -20℃ to 80℃; (4)Built-in Capacitors (Reference): 33 pF.

Features

EFOS4004E5 features: (1)Encased in ceramic package; (2)High reliability against soldering heat and mechanical stress; (3)Moisture-proof sealing; (4)Low Profile Type (1.8 mm maximum in thickness); (5)Designed for reflow soldering; (6)Flat-bottom plate for better mounting; (7)Simplifies oscillation circuits.

Diagrams

EFOS4004E5 package dimensions
