Product Summary

The LM317MDT is a adjustable 3-terminal positive voltage regulator. The LM317MDT is capable of supplying in excess of 1.5A over a 1.2V to 37V output range. It is exceptionally easy to use and require only two external resistors to set the output voltage. Further, both line and load regulation are better than standard fixed regulators.

Parametrics

LM317MDT absolute maximum ratings: (1)Power Dissipation:Internally Limited; (2)Input-Output Voltage Differential:+40V, -0.3V; (3)Storage Temperature:-65℃ to +150℃; (4)Lead Temperature:Metal Package (Soldering, 10 seconds):300℃,Plastic Package (Soldering, 4 seconds):260℃; (5)ESD Tolerance:3 kV.

Features

LM317MDT features: (1)Guaranteed 1% output voltage tolerance; (2)Guaranteed max. 0.01%/V line regulation; (3)Guaranteed 1.5A output current; (4)Adjustable output down to 1.2V; (5)Current limit constant with temperature; (6)P+ Product Enhancement tested; (7)80 dB ripple rejection; (8)Output is short-circuit protected.

Diagrams

LM317MDT pin diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM317MDT
LM317MDT

National Semiconductor (TI)

Linear Regulators - Standard

Data Sheet

0-825: $0.47
825-1050: $0.33
1050-2550: $0.31
2550-5025: $0.30
LM317MDT/NOPB
LM317MDT/NOPB

National Semiconductor (TI)

Linear Regulators - Standard 3-TERMINAL ADJ REG

Data Sheet

0-1: $0.79
1-25: $0.62
25-100: $0.55
100-250: $0.48
LM317MDTRKG
LM317MDTRKG

ON Semiconductor

Linear Regulators - Standard 500mA ADJ 1.2-37V Positive

Data Sheet

0-1: $0.38
1-25: $0.30
25-100: $0.26
100-500: $0.19
LM317MDTG
LM317MDTG

ON Semiconductor

Linear Regulators - Standard 500mA ADJ 1.2-37V Positive

Data Sheet

0-1: $0.35
1-25: $0.29
25-100: $0.21
100-500: $0.17
LM317MDT-TR
LM317MDT-TR

STMicroelectronics

Linear Regulators - Standard 1.2-37V Adj Positive

Data Sheet

0-1: $0.34
1-10: $0.28
10-100: $0.21
100-250: $0.18
LM317MDTRK
LM317MDTRK

ON Semiconductor

Linear Regulators - Standard 500mA ADJ 1.2-37V

Data Sheet

Negotiable
LM317MDTXM
LM317MDTXM

Fairchild Semiconductor

Linear Regulators - Standard Positive adj Reg 3Terminal

Data Sheet

0-1: $0.37
1-25: $0.29
25-100: $0.25
100-250: $0.22
LM317MDTX/NOPB
LM317MDTX/NOPB

National Semiconductor (TI)

Linear Regulators - Standard

Data Sheet

0-1: $1.04
1-25: $0.76
25-100: $0.55
100-250: $0.41
