Product Summary
The HC5549CM is a Low Power SLIC with Battery Switch, and it is a 100V diellectrically isolated bipolar integrated circuit for use in short loop ISDN, PABX and Pairgain applications. The HC5549CM has been optimized for low power as required for battery backed remote terminals or for applications requiring emergency powering from the line such as European ISDN NT1+ designs.
Parametrics
HC5549CM absolute maximum ratings: (1)VCC: -0.5V to +7V; (2)VCC - VBAT: 80V; (3)Maximum Tip/Ring Negative Voltage Pulse: -115V; (4)Maximum Tip/Ring Positive Voltage Pulse: 8V; (5)Uncommitted Switch Voltage: -80V; (6)ESD (Human Body Model): 500V.
Features
HC5549CM features: (1)Dual Battery Operation; (2)Single Additional +5V Supply; (3)Low Standby Power Consumption (48V, 35mW); (4)On Hook Transmission; (5)Tip and Ring Disconnect; (6)Soft or Hard Polarity Reversal; (7)Supports 12kHz or 16kHz Pulse Metering; (8)Ring Relay Driver; (9)On Chip 2-wire AC/DC Loopback; (10)0℃ to 70℃ or -40℃ to 85℃ Ambient Temp Range; (11)Low External Component Count; (12)Pb-Free Available (RoHS Compliant).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HC5549CM |
Intersil |
IC SLIC LP W/BATTERY SW 28-PLCC |
Data Sheet |
|
|
||||||
|
HC5549CMZ |
Intersil |
IC SLIC LP W/BATTERY SW 28-PLCC |
Data Sheet |
|
|
||||||
