Product Summary
The LMH6622MAX is a dual high speed voltage feedback operational amplifier specifically optimized for low noise. The LMH6622MAX operates from ±2.5V to ±6V in dual supply mode and from +5V to +12V in single supply configuration. The LMH6622MAX is stable for AV ≧ 2 orAV ≦ -1. The fabrication of the LMH6622MAX on National Semiconductor’s advanced VIP10 process enables excellent (160MHz) bandwidth at a current consumption of only 4.3mA/amplifier.
Parametrics
LMH6622MAX absolute maximum ratings: (1)ESD Tolerance Human Body Model: 2kV; (2)VIN Differential: ±1.2V; (3)Supply Voltage (V+ – V-): 13.2V; (4)Voltage at Input Pins: V+ +0.5V, V- -0.5V; (5)Soldering Information Infrared or Convection (20 sec): 235℃; (6)Supply Voltage (V+– V-): ±2.25V to ±6V; (7)Junction Temperature Range: -40℃ to +85℃.
Features
LMH6622MAX features: (1)Bandwidth (AV = +2): 160MHz; (2)Supply Voltage Range ±2.5V to ±6V: +5V to +12; (3)Slew rate: 85V/μs; (4)Supply current: 4.3mA/amp; (5)Input common mode voltage: -4.75V to +5.7V; (6)Output Voltage Swing (RL = 100Ω): ±4.6V; (7)Linear output current: 90mA; (8)Excellent harmonic distortion: 90dBc.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LMH6622MAX |
National Semiconductor (TI) |
Operational Amplifiers - Op Amps |
Data Sheet |
|
|
||||||||||
 |
LMH6622MAX/NOPB |
National Semiconductor (TI) |
Operational Amplifiers - Op Amps |
Data Sheet |
|
|
||||||||||
