Product Summary

The PC16550DV is a Universal Asynchronous Receiver/Transmitter with FIFOs. The PC16550DV can be put into an alternate mode (FIFO mode) to relieve the CPU of excessive software overhead.

Parametrics

PC16550DV absolute maximum ratings: (1)Temperature Under Bias: 0℃ to +70℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input or Output Voltages with Respect to VSS: -0.5V to +7.0V; (4)Power Dissipation: 1W.

Features

PC16550DV features: (1)Capable of running all existing 16450 software; (2)After reset, all registers are identical to the 16450 register set; (3)Adds or deletes standard asynchronous communication bits (start, stop, and parity) to or from the serial data; (4)Holding and shift registers in the 16450 Mode eliminate the need for precise synchronization between the CPU and serial data; (5)Independently controlled transmit, receive, line status, and data set interrupts.

Diagrams

PC16550DV pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PC16550DV
PC16550DV
National Semiconductor (TI)
UART Interface IC
Data Sheet
0-1: $4.05
1-25: $3.32
25-100: $2.99
100-250: $2.75
PC16550DV/NOPB
PC16550DV/NOPB
National Semiconductor (TI)
UART Interface IC UART W/ FIFO IN PCC
Data Sheet
0-1: $4.05
1-25: $3.32
25-100: $2.99
100-250: $2.75
PC16550DVX/NOPB
PC16550DVX/NOPB
National Semiconductor (TI)
UART Interface IC
Data Sheet
0-1: $4.89
1-25: $4.01
25-100: $3.62
100-250: $3.32
250-500: $2.51
PC16550DVX
PC16550DVX
National Semiconductor (TI)
UART Interface IC
Data Sheet
0-500: $2.50
500-1000: $2.18
1000-2500: $2.10
